One-Stop Solution
For Railway Locomotive, High Speed Train and Subways
YZPST takes power semiconductor components as the main line. Combined with monolithic integration of fast thyristor and fast diode, small size and less weight, high reliability, less on-state losses elaborate SCRs, TRIACs, Litz Wire, DC-Link Capacitor and Automotive (Press Fit) Diodes to provide customers with one-stop solution. Our products are exported to Europe, America, South America, Middle East and Asia.
YZPST can provide Following List of Induction Heating Capacitor Which are Equivalent as GE
| Type | Voltage (Kv) | Cap. (Kvar) | Frequency (Khz) | Cap.Value | L(mm) | W(mm) | H(mm) |
| RAM0.55-1089-3.2S | 0.55 | 1089 | 3.2 | 179.1 | 342.9 | 136.7 | 342.9 |
| RAM0.625-883-1.2SS | 0.625 | 883 | 1.2 | 299.9 | 342.9 | 136.7 | 330.2 |
| RAM1.0-3000-0.3S | 1 | 3000 | 0.3 | 1592.3 | 558.8 | 203.2 | 711.2 |
| RAM1.2-200-0.06S | 1.2 | 200 | 3.2 | 6.9 | 342.9 | 111.3 | 393.7 |
| RAM1.25-3000-10S | 1.25 | 3000 | 10 | 30.5 | 330.2 | 127 | 342.9 |
| RAM1.5-2333-3S | 1.5 | 2333 | 3 | 55.1 | 342.9 | 111.3 | 330.2 |
| RAM1.8-2442-1.2S | 1.8 | 2442 | 1.2 | 100.1 | 558.8 | 114.3 | 342.9 |
| RAM2.2-4000-0.3S | 2.2 | 4000 | 0.3 | 438.6 | 558.8 | 203.2 | 711.2 |
| RAM2.4-62-0.3S | 2.4 | 62 | 0.3 | 5.7 | 203.2 | 101.6 | 282.7 |
| RAM2.25-49-0.15S | 2.25 | 49 | 0.15 | 10.2 | 203.2 | 101.6 | 282.7 |
| RAM2.8-4000-0.3S | 2.8 | 4000 | 0.3 | 270.8 | 558.8 | 203.2 | 711.2 |
| RAM2.8-4800-0.4S | 2.8 | 4800 | 0.4 | 243.7 | 558.8 | 184.1 | 711.2 |
| RAM3.0-118-0.7S | 3 | 118 | 0.7 | 2.9 | 203.2 | 101.6 | 282.7 |
| RAM3.0-5450-0.7S | 3 | 5450 | 0.7 | 137.8 | 330 | 215 | 640 |
| RAM3.0-8400-0.7S | 3 | 8400 | 0.7 | 212.3 | 558.8 | 203.2 | 711.2 |
| RAM3.0-13400-1.2S | 3 | 13400 | 1.2 | 197.5 | 558.8 | 203.2 | 711.2 |
| RAM3.6-6000-0.5S | 3.6 | 6000 | 0.5 | 147.4 | 330 | 290 | 850 |
| RAM4.0-7500-0.4S | 4 | 7500 | 0.4 | 74.6 | 330 | 340 | 895 |
| RAM5.0-8000-0.4S | 5 | 8000 | 0.4 | 127.4 | 330 | 390 | 825 |
| RAM6.0-6000-0.3S | 6 | 6000 | 0.3 | 88.5 | 330 | 390 | 720 |
| DCMJ0.9-1640S | 0.9 | 1640 | 342.9 | 124 | 450.8 | ||
| DCMJ0.9-5000S | 0.9 | 5000 | 558.8 | 149.4 | 673.1 |
YZPST can provide Following Equivalent List of Fast/Inverter Diodes.
|
FAST/INVERTER DIODES |
||||
|
TYPE |
Equivalent |
IAV |
PIV |
DIA/HT |
|
A696L |
9110/SM18CXC724/M1022LC180 |
1000A |
1800V |
34/27 |
|
3178 |
SM18CXC924/M149NC180 |
1496A |
1800V |
47/27 |
|
M1494 |
SW25CXC924 |
1494A |
2500V |
47/27 |
|
ZWDQ8 |
L5646/ZWDQ 815645 fast recovery stud diode |
|
||
YZPST can provide Following Equivalent List of Discharge Diodes.
|
DISCHARGE DIODES |
||||
|
TYPE |
Equivalent |
IAV |
PIV |
DIA/HT |
|
A740L |
2181/W2416NC200 |
2400A |
2000V |
47/27 |
|
D860 |
2505/2506 |
860A |
1800V |
Square base |
YZPST can provide Following Equivalent List of Snubber Diodes.
|
SNUBBER DIODES |
||||
|
TYPE |
Equivaieni |
IAV |
PIV |
DIA/HT |
|
PHN 100 |
2179 |
100A |
1600V |
Stud Type |
|
PHE 100 |
2180 |
100A |
1600V |
Stud Type |
YZPST can provide Following Equivalent List of SCR and triac.
|
2P4M |
BT2588 |
Q6006 |
SCF6C60 |
TS820 |
|
2P6M |
BY169 |
Q8006 |
S6012 |
TS420 |
|
25TTS16 |
BT169 |
Q6008 |
S8012 |
TYN612 |
|
40TPS16 |
BT151S |
Q8008 |
S8016 |
TYN616 |
|
70TPS16 |
BT148W |
Q6010 |
SCF25C60 |
TYN816 |
|
|
BT148S |
Q8010 |
S6025 |
TYN620 |
|
CR08AS |
BT151 |
Q6016 |
S8025 |
TYN820 |
|
C106 |
BT152 |
Q8016 |
SK025 |
TYN1025 |
|
CS30 |
BTW69 |
Q6025 |
S6035 |
TYN1225 |
|
CS45 |
BT131 |
Q8025 |
S8035 |
TYN630 |
|
CS60-16i01 |
BT134 |
QK025 |
SK035 |
TYN830 |
|
|
BT136 |
Q6040 |
S6040 |
TYN640 |
|
MCR100-6 |
BCR2PM |
Q8040 |
S8040 |
TYN840 |
|
MCR100-8 |
BTA01 |
QK040 |
S6055 |
T405 |
|
...... |
|
