For Welding Application
YZPST takes power semiconductor components as the main line. Combined with high current density, very low on-state voltage drop and ultra-low thermal resistance elaborate welding diode, welding thyristor, welding transformers and ferrites to provide customers with one-stop solution. Our products are exported to Europe, America, South America, Middle East and Asia.
YZPST can provide Following Equivalent List of Welding Thyristors (Capsule Types)
| Type | IT(AV) | VDRM/VRRM | ITSM@TVJM &10ms | IDRM/IRRM (max) Tj=125°C | VTM(max) | Tvj | Rthjc | F±10% | |
| A | V | KA | mA | ITM (A) | ITM (V) | °C | K/W | KN | |
| C280 | 500 | 400-600 | 7200 | 75 | 1000 | 1.35 | 125 | 0.17 | 5 |
| C380 | 960 | 400-600 | 12500 | 100 | 2900 | 1.5 | 150 | 0.09 | 9 |
| C780 | 1350 | 400-600 | 24400 | 80 | 3600 | 1.45 | 125 | 0.055 | 15 |
| Cl 280 | 2310 | 400-600 | 42500 | 80 | 8000 | 1.55 | 125 | 0.025 | 26 |
YZPST can provide Following Equivalent List of Welding Diodes (Capsule Types)
| Type | IF(AV) @TC= 85°C | VRRM | IRRM (max )7 &Tj= | V(TO) Tjmax | RT Tjmax | Tjmax | Rthjc | F±10% |
| Tjmax | ||||||||
| A | V | mA | V | mQ | °C | K/W | KN | |
| 6000N40 | 7100 | 200-600 | 50 | 0.7 | 0.029 | 170 | 0.01 | 28 |
YZPST can provide Following Equivalent List of Housingless Diode
| Type | Sym | A | B | C | H |
| 38DN06 | mm | 2 | 34 | 38 | 4.1 |
